DESCRIPTION

Overview

Basic Info.

Model NO.	SFQ300
Thread Type	NPT
Measuring Medium	Liquid
IP Rating	IP67
Certification	CE RoHS
Customized	Customized
Burst Pressure	200%-300%
Sensitive Component Material	17-4pH
Long-Term Stability	±0.2%F.S/Year
Overload Pressure	4000%/1000% and ≤40ompa/≤40ompa
Accuracy	±0.25%F.S, ±0.5%F.S, ±1%F.S
Power Supply	8-32VDC
Output	4-20mA, 0.5-4.5V, 0.5-4.5V(Ratiometric), 0-10V
Pressure Range	1-10/16-40/60/70-100 MPa
Transport Package	Carton Box
Trademark	Macsensor
Origin	China
Production Capacity	50000/Month

Product Description

Product Description

Engineered for Exceptional Performance in Harsh Conditions

The SFQ300 Series sputtered thin film pressure sensor is the ultimate solution to combat severe challenges encounteredin demanding environments. Designed to tackle issues like cavitation, liquid hammer phenomenon, high pressure spikes,large power fluctuation, and intense vibration interference, this heavy duty pressure transducer surpasses expectations.Its outstanding features provide superior impact resistance, high temperature endurance, dependable long-term stability,and unwavering reliability.

Significance in Various Industries: The SFQ300 heavy-duty pressure transducer holds immense significance across a widerange of industries, including heavy-duty equipment, hydraulic systems, and mobile working machines, etc. Its advancedcapabilities translate into tangible benefits that drive business success.

1. Increased Productivity: With the SFQ300, businesses experience a substantial boost in productivity. Its preciseand accurate pressure measurements enable optimal control, resulting in enhanced operational efficiency andoutput. By maintaining the ideal pressure levels, the thin film pressure sensor ensures smooth equipmentoperation and minimizes costly downtime.

2. Improved Safety: Safety is paramount, especially in industries where heavy-duty machinery and hydraulicsystems are utilized. The SFQ300 pressure transmitter plays a pivotal role in enhancing safety by detectingabnormal or dangerous pressure levels promptly. This proactive approach empowers operators to take preventivemeasures, preventing equipment damage, leaks, and accidents. With the SFQ300, you can prioritize the well-beingof your workforce and create a safer working environment.

3. Reduced Maintenance Costs: Equipment maintenance can be a significant expense, impacting the bottom line.The SFQ300 sensor mitigates these costs by providing accurate pressure readings and preventing unnecessarywear and tear. By detecting pressure anomalies and irregularities, it enables timely maintenance interventions,optimizing the lifespan of the equipment and reducing costly repairs.

4. Enhanced Performance: Achieve unparalleled performance with the SFQ300 pressure transducer. Its ability towithstand harsh conditions, including extreme temperatures and vibrations, ensures optimal sensor functionalityeven in the most challenging environments. With the SFQ300's exceptional durability, you can rely on consistentand accurate pressure measurements, leading to improved overall performance and operational efficiency.

Key Features and Benefits:

• High precision and accuracy: SFQ300 heavy duty pressure transducer provide precise pressure measurements,
• allowing for better control and efficiency in equipment operation.
• Durability and reliability: It has a robust construction to withstand harsh conditions (e.g., extreme temperatures,
• vibration, and shock), and a long lifespan.
• Compact and lightweight: Small size (outer diameter ¢19.6mm, height 47.6±1mm) and low weight, making it
• suitable for integration into various equipment without adding significant bulk.
• Easy installation and maintenance: It can be easily installed and calibrated, reducing downtime and associated costs.
• Compatibility: It can comply with a wide range of hydraulic systems and work seamlessly with existing equipment.

Product Parameters

Parameter	SFQ310 Series
Measuring range(MPa)	1-10	16-40	60	70-100
Burst pressure	300%	300%	250%	200%
Overload pressure	4000%	1000% and ≤40OMPa	≤40OMPa
Accuracy	±0.25%F.S, ±0.5%F.S, ±1%F.S
Long-term stability	±0.2%F.S/year
Output	4-20mA, 0.5-4.5V, 0.5-4.5V(ratiometric), 0-10V
Power Supply	8-32VDC
Zero point temperature drift	±0.1%F.S/10ºC
Full range temperature drift	±0.3%F.S/10ºC
Response time	≤1ms
Durability	10^8pressure circles
lnsulation resistance	≥100OMQ/500VCD
Sensitive component material	17-4PH
lP rating	IP67
Medium temperature range	-40~+80ºC(0.25%F.S), -40~+105ºC(0.5%F.S,1%F.S)
Ambient temperature range	-40~+105ºC
Storage temperature range	-40~+105ºC
Random vibration	20g,GB/T2423.56-2006
Sinusoidal vibration	14.1g,GB/T2423.10-2008
Shock	50g,11ms,GB/T2423.5-1995
EMC-electromagnetic field radiation immunity	GB/T 17626.3-2016
EMC-electrostatic discharge immunity	GB/T 17626.2-2018
Dimensions	Outer diameterΦ 19.6mm, height 47.6±1mm
Electrical Connection	01=M12X1 02=Direct cable outlet 03=Packard connector 04=Hirschmann connector 05=AMP connector 07=Deutsch DT04-4P 08=Deutsch DT04-3P 12=SUMITOMO 6189-0131 13=SUMITOMO 6189-6907

How to order sensors?

To recommend a suitable pressure sensor for you, please kindly confirm the following questions before ordering:

1. Measuring range?

2. Signal Output

3. What's the application? Measuring Medium? Hydraulic oil, gas or others?

4. Process connection?

5. Other special requirements?

The price here is just for reference. Each product will be customized based on your project demand, please send an inquiry to get the optimized product solutions and the best price. Please leave your email address so that our sales engineer can offer one-to-one service for you!
